travel motor

motor type

permanent magnet synchronous servo motor

Motor power       kW

0.4

voltage        V①

48

Rated current       A

10.1

Rated torque     Nm

1.27

Rated speed      r/min

3000

Speed fbk sel

 Incremental encoder

Gearbox

Reducer type

Secondary  gear reduction

Reduction ratio

45.5：1

Brake

Brake torque   Nm

4

Rated voltage    V

DC24

Tyre

Wheel material

Polyurethan/Solid rubber

Wheel size

φ155X55

Steering part

motor type

permanent magnet synchronous servo motor

Motor power       kW

0.2

voltage        V①

48

Rated current       A

5.1

Rated torque     Nm

0.64

Rated speed      r/min

3000

Reducer type

Secondary planetary gear reduction

Reduction ratio

138.6:1

Speed fbk sel

Absolute encoder

Other

Steering limit angle°

±130°

Travel speed  m/min

0-32

Rated traction   N

670

Carrying capacity  Kg

300

net weight         Kg

24
