travel motor

motor type

permanent magnet synchronous servo motor

Motor power       kW

0.75

voltage     V^①

48

Rated current A

19

Rated torque Nm

71

Rated speed r/min

3000

Speed fbk sel

Incremental encoder

Gearbox

Reducer type

Secondary  gear reduction

Reduction ratio

31.67：1

Brake

Brake torque Nm

4

Rated voltage    V

DC24

Tyre

Wheel material

Polyurethan/Solid rubber

Wheel size

φ200X60

Steering part

motor type

permanent magnet synchronous servo motor

Motor power kW

0.2

voltage   V^①

48

Rated current A

5.1

Rated torque    Nm

0.64

Rated speed r/min

3000

Reducer type

Secondary planetary gear reduction

Reduction ratio

138.6:1

Speed fbk sel

Absolute encoder

Other

Steering limit angle°

±130°

Travel speed     m/min

0-32

Rated traction  N

670

Carrying capacity   Kg

300

net weight    Kg

24
